ATTENTION INSTALLER – VERIFY PRIOR TO INSTALLATION:
Check for shipping damage immediately upon receipt.
Note any freight damage on freight bill while driver is still present. In most cases, freight damage claims will not be
allowed unless noted on the freight bill. Pictures of damage before the unit is unpacked can be very helpful.
Contact shipper right away with any freight damage concerns.
The VPL is shipped with a packing list. Ensure all items are present before starting installation.
Layout installation site taking into consideration VPL entry and exit points, height, and electrical supply location.
The VPL platform must be at least 3/8” but no more than 3/4” from the edge of the upper landing (horizontally).
The VPL platform guard walls must be at least 2” but no more than 3” (horizontally) from walls or other obstructions.
It is the installer’s responsibility to verify local codes and regulations regarding power supply and electrical
connections. The VPL is supplied with a 12’ power cord.
The VPL must be anchored to a level, 3,500 PSI concrete pad at least 4” thick. The minimum pad dimensions are
41” x 50” to anchor the legs and support the tower. However, a larger pad will be needed if it is desired that the
guard ramp land on the pad and/or the approach to the ramp be incorporated into the pad. Final pad location,
orientation and dimensions are the installer’s responsibility to determine based on field conditions.
Confirm the structural integrity of any existing fascia.
Verify that the upper landing area is level.
Determine which side of the VPL the guard ramp will be attached to and make sure there is adequate clearance at
the lower landing to access the ramp.
Check for adequate headroom clearance above VPL platform. The 52” VPL requires approximately 100” to travel to
its maximum height not including the occupant.
Verify adequate running clearances for the VPL. The platform must be able to travel up and down and the guard
ramp must be able to fold and unfold without interference or obstruction.
Refer to the Top Landing Gate Placement and Installation section if installing a Top Landing Gate.
Read and understand the entire Installation Manual before proceeding with installation.
Please leave User Manual with the VPL user.
TABLE OF CONTENTS
Section 1 - - - - Symbols, Safety and Warnings
Section 2 - - - - Labeling and Dealer Contact Information
Section 3 - - - - Optional Equipment Notice
Section 4 - - - - Assembling the VPL
Section 5 - - - - Optional Equipment - Wireless Remote
Section 6 - - - - Optional Equipment - Top Landing Gate
Section 7 - - - - - - - Top Landing Gate Optional Equipment - Pathway Connector Kit
Section 8 - - - - - - - Top Landing Gate Optional Equipment - Deck Connector Kit
Section 9 - - - - Optional Equipment - Platform Safety Rail
Section 10 - - - - Optional Equipment - Platform Safety Pan Weather Guard
Section 11 - - - - Optional Equipment - Interlock
Section 12 - - - - Optional Equipment - Call/Send Control
Section 13 - - - - - - - Call/Send Control Optional Equipment - Call/Send Control Mounting Kit
Section 14 - - - - Maintenance and Service
Section 15 - - - - Electrical Drawings
See User Manual - - - - Features
- - - - Operation
- - - - Emergency Operation
- - - - Specifications
- - - - Troubleshooting
- - - - Main Components Drawing and Overall Dimensions (52” VPL)
- - - - Warranty
