Ezee-On 4290 - Specifications

Page 5
SPECIFICATIONS
APPROXIMATE NO. OF GANG WING LIFT CYL. GANG BEARING TYPE
MODEL BLADE SPACING CUTTING WIDTH NO. OF BLADES BEARINGS STROKE STD. OPTION
4298 - 50B
4298 - 54B
4298 - 58B
4298 - 62B
4298 - 66B
4298 - 70B
4298 -74B
4299 - 46B
4299 - 50B
4299 - 54B
4299 - 58B
4299 - 62B
4299 - 66B
4309 - 46B
4309 - 50B
4309 - 54B
4309 - 58B
4309 - 62B
4309 -66B
4300 - 42B
4300 - 46B
4300 - 50B
4300 - 54B
4300 - 58B
8" (203 mm)
8" (203 mm)
8" (203 mm)
8" (203 mm)
8" (203 mm)
8" (203 mm)
8" (203 mm)
9" (229 mm)
9" (229 mm)
9" (229 mm)
9" (229 mm)
9" (229 mm)
9" (229 mm)
9" (229 mm)
9" (229 mm)
9" (229 mm)
9" (229 mm)
9" (229 mm)
9" (229 mm)
10-1/2" (267 mm)
10-1/2" (267 mm)
10-1/2" (267 mm)
10-1/2" (267 mm)
10-1/2" (267 mm)
17' (5.18 m)
18-1/2' (5.63 m)
20' (6.09 m)
21' (6.40 m)
22-1/2' (6.85 m)
24' (7.31 m)
25-1/2' (7.77 m)
18' (5.48 m)
19-1/2' (5.94 m)
21' (6.40 m)
22' (6.70 m)
23-1/2' (7.16 m)
25' (7.62 m)
18' (5.48 m)
19-1/2' (5.94 m)
21' (6.40 m)
22' (6.70 m)
23-1/2' (7.16 m)
25' (7.62 m)
18-1/2' (5.63 m)
20' (6.09 m)
22' (6.70 m)
23-1/2' (7.16 m)
25' (7.62 m)
50
54
58
62
66
70
74
46
50
54
58
62
66
46
50
54
58
62
66
42
46
50
54
58
12
12
14
18
22
22
24
12
12
16
20
20
22
12
12
16
20
20
22
12
12
16
16
18
34-3/4" (883 mm)
34-3/4" (883 mm)
34-3/4" (883 mm)
36" (914 mm)
36" (914 mm)
36" (914 mm)
36" (914 mm)
34-3/4" (883 mm)
34-3/4" (883 mm)
36" (914 mm)
36" (914 mm)
36" (914 mm)
36" (914 mm)
34-3/4" (883 mm)
34-3/4" (883 mm)
36" (914 mm)
36" (914 mm)
36" (914 mm)
36" (914 mm)
34-3/4" (883 mm)
34-3/4" (883 mm)
36" (914 mm)
36" (914 mm)
36" (914 mm)
211
211
211
211
211
211
211
211
211
211
211
211
410
410
410
410
410
410
410
410
410
410
410
410
410
410
410
410
410
410
410
410
410
410
410
---
---
---
---
---
---
T2-215
T2-215
T2-215
T2-215
T2-215
TIRES
MODEL SIZE
TOTAL
NO. of
WHEELS
OUTER
WHEEL
TYPE
M/F TIRES W/F TIRES
SIZE PRESSURE SIZE PRESSURE
4290 17' - 19-1/2' (5.18 m - 5.94 m) 4 Single 11L x 15 F1 Load Range “C” 45 11L x 15 F1 Load Range “C” 45
4290 20' - 25-1/2' (6.09 m - 7.77 m) 6 Dual 11L x 15 F1 Load Range “C” 45 11L x 15 F1 Load Range “C” 45
4300 18' - 20' (5.48 m - 6.09 m) 4 Single 11L x 15 F1 Load Range “D” 60 11L x 15 F1 Load Range “C” 45
4300 21' - 25' (6.40 m - 7.62 m) 6 Dual 11L x 15 F1 Load Range “D” 60 11L x 15 F1 Load Range “C” 45
GANG ANGLE - Front Gang - Adjustable - 22 and 25 degrees HYDRAULIC CYLINDERS - Wing Lift (1) - 5" x 36" (127 mm x 914 mm)
- Rear Gang - Adjustable - 20 and 23 degrees Lift (1) - 3-1/2" x 24" Rephasing (88.9 mm x 610 mm)
(1) - 3" x 24" Rephasing (76.2 mm x 610 mm)
BOLT TORQUES - Gang Bolts - 1-15/16" (49 mm) Diameter 3200 ft. lbs. (4336 N.m)
Gang Beam Bolts - 1-1/4" (31.7 mm) Diameter 840 ft. lbs. (1138.2 N.m)
Levelling Crank Bolts - 1-1/4" (31.7 mm) Diameter 840 ft. lbs. (1138.2 N.m)
Wheel Bolts - 9/16" (14.2 mm) Diameter 130 ft. lbs. (176.2 N.m)
Bearing Hanger U-Bolts - Model 4290 - 5/8" (15.7 mm) Diameter 150 ft. lbs. (203.25 N.m.) - Solid Hangers
- 3/4" (19 mm) Diameter 260 ft. lbs. (352.3 N.m.) - Stone Flex Hangers
- Model 4300 - 7/8" (22 mm) Diameter 430 ft. lbs. (582.65 N.m.)
GANG BEARINGS
