Repair and Service Manual
B
HANDHELD DIAGNOSTICS
Read all of Section B and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
Monitor
Fault Counters
Main Welded 0 - 255 -
Speed Sensor Fault 0 - 255 -
Main Driver On 0 - 255 -
Main Coil Open 0 - 255 -
Main Dropout 1 0 - 255 -
Motor Stall 0 - 255 -
Main Driver Off 0 - 255 -
Main Dropout 2 0 - 255 -
Curent Sense Fault 0 - 255 -
M - Shorted 0 - 255 -
Field Missing 0 - 255 -
Hardware Failsafe 0 - 255 -
Fault Counter
Hour Meter
Throttle Fault 0 - 100000 Hrs
Low Battery Voltage 0 - 100000 Hrs
Overvoltage 0 - 100000 Hrs
Thermal Cutback 0 - 100000 Hrs
HPD 0 - 100000 Hrs
Main Drvr OverCurrent 0 - 100000 Hrs
Neg la 250 0 - 100000 Hrs
Neg la 300 0 - 100000 Hrs
Main Welded 0 - 100000 Hrs
Speed Sensor Fault 0 - 100000 Hrs
Main Driver On 0 - 100000 Hrs
Main Coil Open 0 - 100000 Hrs
Main Dropout 1 0 - 100000 Hrs
Motor Stall 0 - 100000 Hrs
Main Driver Off 0 - 100000 Hrs
Main Dropout 2 0 - 100000 Hrs
Curent Sense Fault 0 - 100000 Hrs
M - Shorted 0 - 100000 Hrs
Field Missing 0 - 100000 Hrs
Hardware Failsafe 0 - 100000 Hrs
Faults
System Faults Display active faults.
Fault History Display non-active (past) faults.
Clear Fault
History
YES / NO
Functions Settings
Get Settings From Controller OK / ABORT
Write Settings to Controller OK / ABORT
Reset All Settings YES / NO
Information
Model Number Display controller model number
Serial Number Display controller serial number
Software Number Display controller software number
Hardware Version Display controller hardware version
Protocol Version Display controller protocol version
Param Block
Version
Display controller param block version
Menu Submenu 1 Submenu 2 Submenu 3 Data Range
Default
Value
Units
