Where applicable, THE USE OF NON UL PARTS WILL VOID ANY UL LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
G** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
Page L-2
Service Parts Manual
REAR AXLE
1 74612-G01 REAR AXLE ASSEMBLY 14.76:1 (INCLUDES ITEMS 2 - 7) ............................. 1
2 20377-G12 AXLE SHAFT (PASSENGER SIDE)............................................................. 1
3 20377-G11 AXLE SHAFT (DRIVER SIDE)...................................................................... 1
4 * DIFFERENTIAL COVER............................................................................... 1
5 28610-G01 FILL PLUG WITH 'O' RING........................................................................... 1
6 15558-G1 BOLT, 5/16 - 18 X 3/4" LG............................................................................. 10
7 73050-G01 VENT ............................................................................................................ 1
8
9 72763-G02 SCUFF GUARD .................................................................................................. 1
10
11 24261-G1 SPLINE BUMPER ............................................................................................... 1
12 00797-G2 BOLT, 1/4 - 20 X 1 1/4" LG.................................................................................. 3
13 00664-G7 LOCK WASHER, 1/4" (STAINLESS STEEL) ...................................................... 3
14 01110-G01 WASHER, 1/4" (STAINLESS STEEL) ................................................................. 3
15 28095-G01 MOLY LUBE, 2 OZ. ............................................................................................. AR
