Ezviz C2c User Manual

4
Box Content
Internet Camera (x1) USB Cable (x1) Power Adapter (x1)
Foam Sticker X2
Metal Plate X1
(3.5mm Hole Diameter
）
Quick Start Guide X1
Installing Memory Card
Insert a microSD card into the slot until a click.
Initializing Memory Card
1. In the EZVIZ app, check the memory card status by tapping on the Storage Status in the
Device Settings interface.
2. If the memory card status displays as Uninitialized, tap to initialize it. The status will then
change to Normal. You can then start recording any event triggered video in the camera such
as motion detection.

Ezviz C2c Specifications

General

Type	IP security camera
Certification	FCC/UL/CE/RoHS/WEEE/REACH
Placement supported	Indoor
Connectivity technology	Wireless
Infrared (IR) cut-off filter	Yes
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB
Sensor type	CMOS
Number of sensors	1
Optical sensor size	1/3 \
Fixed focal length	2.8 mm
Minimum illumination	0 lx
Total megapixels	- MP
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p
Video compression formats	H.264, H.265
Noise reduction technology	3D noise reduction
Cables included	USB
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Audio system	2-way
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Wi-Fi data rate (max)	72 Mbit/s
Operating temperature (T-T)	-10 - 45 °C
Operating relative humidity (H-H)	0 - 95 %
DC output current	1 A
DC output voltage	5
Power source type	DC
Power consumption (max)	4 W
Form factor	-
Mounting type	Ceiling/wall
Product color	White
Night vision distance	10 m

Weight and Dimensions

Depth	58 mm
Width	38 mm
Height	110 mm
Weight	100 g
Package depth	91.5 mm
Package width	149 mm
Package height	87.5 mm
Package weight	292 g
