Ezviz C2c User Manual

1
Setup
Step 1 Power-on
Plug the power cable into the camera and to the power adapter and then into a power
outlet, as shown in the figure below.
Power Cable
Power Outlet
Step 2 Camera Setup
1. Create an user account
- Connect your mobile phone to Wi-Fi.
- Download and install the EZVIZ app by searching “EZVIZ” in App Store and Google
Play
TM
.
- Launch the app and register for an EZVIZ user account following the start-up
wizard.
2. Add a camera to EZVIZ
- Log in the EZVIZ app.
- From the EZVIZ app Home screen, tap “+” on the upper-right hand corner to go to
the scan QR code interface.
- Scan the QR Code on the bottom of the camera.
Bottom of the Camera
- Follow the EZVIZ app wizard to finish Wi-Fi configuration.

Ezviz C2c Specifications

General

Type	IP security camera
Certification	FCC/UL/CE/RoHS/WEEE/REACH
Placement supported	Indoor
Connectivity technology	Wireless
Infrared (IR) cut-off filter	Yes
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB
Sensor type	CMOS
Number of sensors	1
Optical sensor size	1/3 \
Fixed focal length	2.8 mm
Minimum illumination	0 lx
Total megapixels	- MP
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p
Video compression formats	H.264, H.265
Noise reduction technology	3D noise reduction
Cables included	USB
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Audio system	2-way
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Wi-Fi data rate (max)	72 Mbit/s
Operating temperature (T-T)	-10 - 45 °C
Operating relative humidity (H-H)	0 - 95 %
DC output current	1 A
DC output voltage	5
Power source type	DC
Power consumption (max)	4 W
Form factor	-
Mounting type	Ceiling/wall
Product color	White
Night vision distance	10 m

Weight and Dimensions

Depth	58 mm
Width	38 mm
Height	110 mm
Weight	100 g
Package depth	91.5 mm
Package width	149 mm
Package height	87.5 mm
Package weight	292 g
