Ezviz C6CN User Manual

1
Setup
Step 1 Power-on
Plug the power cable into the camera, and then plug the power adapter into an outlet as shown
in the figure below.
Power Outlet
Power Cable
Power Interface
LED Indicator Status
Solid Red: Camera is starting up.
Slowly Flashing Red: Wi-Fi connection has failed.
Fastly Flashing Red: Device exception (e.g. MicroSD
card error).
Solid Blue: Video is being viewed or played back in
EZVIZ App.
Fastly Flashing Blue: Camera is ready for the Wi-Fi
connection.
Slowly Flashing Blue: Camera is running properly.
Turn on the camera and let it power up. The camera will completely rotate side-to-side and
tilt up-and-down once.

Ezviz C6CN Specifications

General

Type	IP security camera
Antenna type	Internal
Auto-tracking	Yes
Operating frequency	2.4 - 2.4835 MHz
Placement supported	Indoor
Connectivity technology	Wired & Wireless
Form factor	Spherical
Mounting type	Ceiling/Wall/Desk
Product color	Black, White
Tilt angle range	-15 - 105 °
Minimum illumination	- lx
Adjustment shutter speed	Auto
Sensor type	CMOS
Number of sensors	-
Optical sensor size	1/2.9 \
Digital zoom	8 x
Lens diameter	4 mm
LED type	IR
Night vision distance	10 m
Total megapixels	- MP
Maximum resolution	1920 x 1080 pixels
Video formats supported	H.264
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB
Wi-Fi standards	Wi-Fi 4 (802.11n)
Wi-Fi data rate (max)	72.2 Mbit/s
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Power source type	USB
Power consumption (max)	5 W

Weight and Dimensions

Width	87.7 mm
Height	112.7 mm
Weight	260 g
Package width	103 mm
Package height	188 mm
