Ezviz C6CN User Manual

3
microSD Card Slot
Reset Button
• If the camera fails to connect to your Wi-Fi network, press and hold the Reset button for 5s
and repeat Step 2.2.
• To select another Wi-Fi network, press and hold the Reset button for 5s to reboot the device.
3. Enable the Image Encryption
After enabling it, your video and image can be encrypted in transmission.
You can also change the default password.
- Go to the camera settings.
- Tap “Change Password”.
- Tap “Edit”.
- Enter the original verification code located on the label of the camera.
- Enter new password (6 to 12 characters and numbers).
4. Angle Adjustment
You can adjust the camera via the EZVIZ app to get an optimum angle.
The panning angle ranges from 0° to 340°, and the tilting angle ranges from -15° to 105°.

Ezviz C6CN Specifications

General

Type	IP security camera
Antenna type	Internal
Auto-tracking	Yes
Operating frequency	2.4 - 2.4835 MHz
Placement supported	Indoor
Connectivity technology	Wired & Wireless
Form factor	Spherical
Mounting type	Ceiling/Wall/Desk
Product color	Black, White
Tilt angle range	-15 - 105 °
Minimum illumination	- lx
Adjustment shutter speed	Auto
Sensor type	CMOS
Number of sensors	-
Optical sensor size	1/2.9 \
Digital zoom	8 x
Lens diameter	4 mm
LED type	IR
Night vision distance	10 m
Total megapixels	- MP
Maximum resolution	1920 x 1080 pixels
Video formats supported	H.264
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB
Wi-Fi standards	Wi-Fi 4 (802.11n)
Wi-Fi data rate (max)	72.2 Mbit/s
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Power source type	USB
Power consumption (max)	5 W

Weight and Dimensions

Width	87.7 mm
Height	112.7 mm
Weight	260 g
Package width	103 mm
Package height	188 mm
