Installation
Trin 1 Tændt
Sæt strømledningen i kameraet, og sæt derefter strømadapteren i en stikkontakt som vist i
figuren nedenfor.
Strømgrænseflade
Strømkabel
Stikkontakt
Tænd kameraet, og lad det starte op. Kameraet drejer helt rundt og vipper én gang op
og ned.
LED-kontrollampe
LED-statusindikator
Lyser konstant rødt: Kamera starter op.
Langsomme røde blink: Wi-fi-forbindelsen er afbrudt.
Hurtige røde blink: Enhedsundtagelse (f.eks.
MicroSD-kortfejl).
Konstant blåt: En video vises eller afspilles
i appen EZVIZ.
Hurtige blå blink: Kameraet er klar til
wi-fi-forbindelsen.
Blinker langsomt: Kameraet fungerer
korrekt.

Ezviz C6T Specifications

General

Type	IP security camera
Placement supported	Indoor
Connectivity technology	Wired & Wireless
Wide Dynamic Range (WDR)	Yes
Tilt angle range	-10 - 80 °
Angle of rotation	340 °
Camera shutter speed	1/30 - 1/1000000 s
Minimum illumination	0.02 lx
Bluetooth	No
Frequency band	2.4 - 2.4835 GHz
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Wi-Fi data rate (max)	150 Mbit/s
Ethernet interface type	Fast Ethernet
LED type	IR
Night vision distance	10 m
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Sensor type	CMOS
Optical sensor size	1/3 \
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	0 - 95 %
DC output voltage	5
Power source type	DC
Power consumption (max)	6 W
Power over Ethernet (PoE)	-
Interface	RJ-45/WLAN
Ethernet LAN (RJ-45) ports	1
Maximum resolution	1920 x 1080 pixels
Video compression formats	H.264
Supported graphics resolutions	1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Lens mount interface	M12
Form factor	Dome
Mounting type	Desk
Product color	Black
Mobile operating systems supported	Android, iOS
Fixed focal length	4 mm
Maximum aperture number	2.2

Weight and Dimensions

Height	90 mm
Weight	220 g
Diameter	100 mm
Package type	Box
Package width	127 mm
Package height	52 mm
