Ezviz C6T User Manual

9
Wireless Magnetic Contact Installing
• The installation place should with no strong magnetic field nearby.
• To ensure the detection effect, the distance of two parts should be as small as possible (within
5mm) when you install them.
1. Selecting the Installation Position
You can install the detector on the door or window, as shown below.
Door Window
2. Installing
Make sure the door or window is closed. Paste the foam sticker to the bottom of the two parts
and then fix them on the selected position, as shown below.
You are recommended to install the main body of the contact on the immovable place (such
as door frame) in case it falls down when you open and close the door or window.

Ezviz C6T Specifications

General

Type	IP security camera
Placement supported	Indoor
Connectivity technology	Wired & Wireless
Wide Dynamic Range (WDR)	Yes
Tilt angle range	-10 - 80 °
Angle of rotation	340 °
Camera shutter speed	1/30 - 1/1000000 s
Minimum illumination	0.02 lx
Bluetooth	No
Frequency band	2.4 - 2.4835 GHz
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Wi-Fi data rate (max)	150 Mbit/s
Ethernet interface type	Fast Ethernet
LED type	IR
Night vision distance	10 m
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Sensor type	CMOS
Optical sensor size	1/3 \
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	0 - 95 %
DC output voltage	5
Power source type	DC
Power consumption (max)	6 W
Power over Ethernet (PoE)	-
Interface	RJ-45/WLAN
Ethernet LAN (RJ-45) ports	1
Maximum resolution	1920 x 1080 pixels
Video compression formats	H.264
Supported graphics resolutions	1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Lens mount interface	M12
Form factor	Dome
Mounting type	Desk
Product color	Black
Mobile operating systems supported	Android, iOS
Fixed focal length	4 mm
Maximum aperture number	2.2

Weight and Dimensions

Height	90 mm
Weight	220 g
Diameter	100 mm
Package type	Box
Package width	127 mm
Package height	52 mm
