FAAC 460-P User Manual

25
ENGLISHENGLISH
Table 9 Standard automatic operating logic
Ü The effects of an active impulse on the other inputs is given in brackets.
(1) An OPEN-A impulse during a pedestrian cycle (OPEN-B), activates both leaves in opening.
(2) If residual pause time is shorter than 5 seconds, it closes after 5 seconds when the safeties are disengaged.
GATE STATUS
CLOSED
OPENING
OPEN ON
PAUSE
CLOSING
STOPPED
OPEN-A
opens leaves and
recloses after pause
time
no effect (1)
recloses leaves
immediately (1)
reopens leaves
immediately
closes the leaves (1)
OPEN-B
opens single leaf and
recloses after pause
time
no effect
recloses leaf/leaves
immediately
reopens leaf/leaves
immediately
closes the leaf/leaves
CLOSE
no effect
no effect
recloses leaf/leaves
immediately
no effect
closes leaf/leaves
STOP
no effect
(OPEN inhibited)
stops
stops
stops
no effect
(OPEN/CLOSE inhibited)
FSW-OP
no effect
(OPEN inhibited)
stops opening and
when disengaged
closes
no effect
-opening inhibited-
no effect
no effect
-opening inhibited-
FSW-CL
no effect
no effect
freezes pause until
disengagement
-closure inhibited-
changes direction and
starts to open
no effect
-closure inhibited-
FSW-OP/CL
no effect
(OPEN inhibited)
stops opening and
when disengaged
continues to open
freezes pause until
disengagement (2)
-OPEN/CLOSE inhibited-
stops and when
disengaged starts to
open
no effect
(OPEN/CLOSE inhibited)
SAFE-OP
no effect
(OPEN inhibited)
reverses movement for
2 seconds then stops
no effect
-opening inhibited-
no effect
no effect
-opening inhibited-
SAFE-CL
no effect
no effect
no effect
-closure inhibited-
reverses movement for
2 seconds then stops
no effect
-closure inhibited-
SAFE-OP/CL
no effect
(OPEN inhibited)
stops movement
➲ when disengaged
OPEN= closes (1)
CLOSE= closes
no effect
(OPEN/CLOSE inhibited)
stops movement
➲ when disengaged
OPEN= opens
CLOSE= closes
no effect
(OPEN/CLOSE inhibited)
LOGIC “A” PULSES
