Faber Chloe - Chimney Kit Mounting and Securing

23
10
+RRN DQG ¿[ WKH KRRG ERG\ RQWR
the wall.
From inside fully secure the 4 screws 12a.
L
2x
4
L
4x
11
12
Use the four
screws(included
with Optional Tele-
scopic Chimney
Kit) to secure the
angle bracket.
13
8
L
4x
M
2x
Fix the
bracket using
the screws
included with
Optional
Telescopic
Chimney Kit.
Installation with the optional Kit Chimney
