12 Table
Find the correct vertical and horizontal lengths in the table.
In case of an “x”, or if the values are outside the table, the combination is not permitted.
The value found indicates the width of the restrictor to be placed ("0" means no restrictor
should be placed).
Generally a 30mm restrictor is pre-installed
Horizontaal
0 1 2 3 4 5 6
0
X X X X X X X
0.5
X X X X X X X
1
0 0 0 X X X X
1.5
30 30 0 0 X X X
2
30 30 30 0 0 0 0
3
40 30 30 30 0 0 0
4
40 40 30 30 30 0 0
5
50 40 40 30 30 30 0
6
50 50 40 40 30 30 0
7
50 50 50 40 40 40 X
8
60 50 50 40 40 X X
9
60 60 50 50 X X X
10
65 60 60 X X X X
11
65 65 X X X X X
Verticaal
12
65 X X X X X X
