Faber STILO User Manual

EN
5
5
CHARACTERISTICS
Dimensions
Components
Ref. Q.ty Product Components
1 1 Hood Body, complete with: Controls, Light, Blower,
Filters
2 1 Telescopic Chimney comprising:
2.1 1 Upper Section
2.2 1 Lower Section
10 1 Ring with Damper
Ref. Q.ty Installation Components
7.2.1 2 Upper Chimney Section Fixing Bracket
11 10 Wall Plugs
12a 10 Screws 4,2 x 44,4
12c 6 Screws 2,9 x 6,5
Q.ty Documentation
1 Instruction Manual
2.1
2.2
2
12c
12a
7.2.1 11
11
12a
1
10

Faber STILO Specifications

General

Width	60 cm
Control Type	Mechanical
Type	Wall-mounted
Body material	Stainless steel
Number of speeds	3
Number of lights	2
Number of Motors	1
Material	Stainless Steel
Filter Type	Grease
Grease filter type	Metallic
