FITTING OF THE SECTIONS
1. fix a connector on the top of all standard
sections.
Do not lock the screws.
2. Put the wire into the top section
3. Insert a black bearing (Rep. B) into the
bottom of the top section
Connect both sections (the bearing will be
pushed up and locked by the connector).
Tighten the 4 screws.
4. insert a bearing (Rep. B) into the 2 M
section and connect it with another standard
section.
5. Continue this operation for the next
sections. Do not forget to insert a bearing.
You must have: a bearing always above
each connector.
6. pass the forestay through the telescopic
section and the black feeder.
7. on the last section, insert a bearing, this one
will be pushed up by the telescopic section.
8. insert the telescopic section into the bottom
section.
Do not fit the screws yet.
