Measuring Diodes (Diode Tester)
Starting from the Resistance position, press the yellow button (secondary
functions) to select the Test Diode function.
Check the circuit to be measured with the contact tips.
Shorted junction indication : beeping for a threshold < 0,050 V
Reversed junction indication : OL
___
displays.
Display Range V
Measurement Range 0 - 3,999 V
Measurement Current 500 µA
Precision 1,5 % ± 2 points
Resolution 0,001 V
Protection 500 V AC or 750 V (DC or Peak)
