Facom 712 - Measuring AC or DC Currents; Measuring Temperature; Without probe

19
Measuring AC or DC Currents (Ammeter)
Set the selector switch to the ammeter function A.
Open the jaws of the alligator clip with the spring catch and insert it on the
conductor where the measurement is to be made.
Release the spring catch and make sure the jaws are in good contact to reclose the
magnetic circuit correctly.
Range switching and AC/DC selection are automatic.
In DC, the residual or zero current may be corrected by pressing and holding the
HOLD button.
In DC current, the maximum current is 400 A.
In A DC, the display indicates : OL
___
above + 399,9 A
OL
___
below - 399,9 A
In A AC, the display indicates : OL above 600 A peak.
Display Range A A A
Measurement 0,20 - 39,99 A 40,0 - 399,9 A 400 - 600 A peak
Range
Precision 1,5% ± 10 points 1,5% ± 2 points 1,5% ± 2 points
Resolution 10 mA 0,1 A 1 A
Measuring Temperature
Without probe
The displayed temperature measurement is that of the tester,
equivalent to the ambient temperature after thermal stabilization.
The T° INT symbols appear on the display.
