Factory CHRISTEN EAGLE II - Page 17

www.seagullmodels.com
17
ELEVATOR - RUDDER PUSHROD -
CONTROL HORN INSTALLATION.
M2 clevis. M2 Lock nut.
Attach to servo arm in fuselage.
Attach to elevator - rudder control horn.
Masking tape.
Elevator control horn .
Elevator pushrod .
Hinge.
C/A glue.
Elevator control horn
M2 lock nut.
Metal clevis
Rudder control horn .
