CHRISTEN EAGLE II Instruction Manual.
6
Aluminum Washer.
CONTROL HORN M3
M3 LOCK NUT.
Epoxy.
Aluminum Washer.
Rudder control horn:
Using the same techniques used aileron
control horn. See picture below.
16mm.
Epoxy.
RUDDER CONTROL HORN.
Horizontal
Stabilizer.
Elevator control horn.
Horizontal
Stabilizer.
Elevator.
2 sets.
3x45mm.
CONTROL HORN
M3 SCREW.
ALUMINUM WASHER.
ALUMINUM WASHER.
M3 LOCK NUT.
EPOXY.
FUSELAGE
Rudder
18mm.
EPOXY.
Fuselage.
Rudder.
Rudder control horn.
See pictures below.Make yourself the
template of your engine on paper.
ENGINE MOUNT INSTALLATION.
M4x30mm.
