fadini Elpro-13 exp - Page 6

1643
Drwg. No.
exp
13
GB
230V SINGLE-PHASE PROGRAMMER FOR SWING GATE OPERATORS
IMPORTANT:
- The programmer must be installed in a protected, dry place with its own protective case
- Apply a high sensitivity dierential Thermo magnet switch type 0.03 A to the programmer’s power supply
- Make sure that the electronic programmer has a 230V
10% 50Hz power supply
- For power supply, ashing light use cable with wires with a section of 1.5 mm
2
up to a distance of 50m; for Limitswitches and other accessories, use cables with
wires with 1mm
2
sections.
- If the Photocells are not used, insert a jumper between terminals 1 and 2 and if the 2nd pair is not used, jumper the relative terminals
- If no Button switches or key switches without stop button are used, insert a jumper between terminals 3 and 6 NC contact
IF THE PROGRAMMER DOES NOT WORK:
- Ensure that the electronic programmer has a 230V
10% power supply
- Ensure that the electric motor has a 230V 10% power supply
- For distances of over 50 metres, increase the section of the wires.
- Check the single-phase 230V supply voltage
- Check the fuses
- Check all normally closed NC contacts of the programmer
- Check that there is no drop in voltage between the programmer and the electric motor
Diagnostic LEDs
L1= ON if the programmer is powered
L2= Photocell, normally ON, switches o with obstacle present
L3= Open, normally OFF, lights when Open pulse is received
L4= Close, normally OFF, lights when Close pulse is received
L5= Stop, normally ON, switches o when Stop impulse is given
L6= Radio, normally OFF, lights when Radio pulse is received
Line fuse
F1= 5A
DIP-SWITCH
ON
OFF
14567823
11
12
13 14 15
T
U
P
T
U
O
A
m
0
52
V4
2
:d
a
o
l
.xam
r
o
f
sr
ia
p
2
-
fo
c
irtce
le
o
t
ohp
s
l
l
e
c
r
ev
iece
r
o
id
a
R
1
-
1
74
10
2
85
3
96
STOP
NC
COMMON
OPEN NO
CLOSE NO
CONTACT
NC
1
t
s
S
L
L
EC
O
T
O
HP f
o
ria
p
OI
DAR NO
CONTACT NC
2
nd
SLL
EC
OT
O
HP
fo
r
i
a
p
xam
W
3
V
4
2
t
hgil
r
o
taci
d
nI
Elpro 13 exp FADINI
COMMON
21
M1
SINGLE-PHASE
230V
MOTOR M1
M2
18
16
17
19
20
COMMON
SUPPORT FOR
PLUG-IN RADIO CARD
-
+
CLOSING LEAF
DELAY TIME
0s - 18s
L1
L6
L3
L4
L5
L2
COMMON
YTEFA
S
NC
CONTACT
24
22
23
25
T
H
GIL
GN
I
HS
AL
F
V
03
2
xa
m
W
52
230V 50Hz
10% SINGLE-PHASE
POWER SUPPLY INPUT
12.5
F
Capacitor
Motor M1
Line fuse
F2= 5A
Flashing light fuse
F3= 630mA
Transformer
fuse
F4= 630mA
Opening Delay
Relay
Closing Delay
Relay
Line relay
Motor M2
direction relay
230V – 24V
Transformer
28
26
27
-
+
DWELL TIME
0s - 120s
-
+
OPERATING TIME
2s - 100s
TERMINAL BOARD FOR
CONNECTING THE PULIN 3
BUTTON SWITCH
12V AC, 15VA POWER
SUPPLY OUTPUT
fuse 24v
F5= 1A
12.5
F
Capacitor
Motor M2
Motor M1
direction relay
SINGLE-PHASE
230V
MOTOR M2
ELECTRIC LOCK
6
General description: The Elpro 13 exp is an electronic microprocessor programmer for controlling and managing single-phase gate openers fitted on swinging gates.
single-phase 230V±10% 50Hz power supply, it satisfies the Low Voltage 2006/95/CE and Electro Magnetic Compatibility regulations 2004/108/CE safety standards and
should therefore be installed by a qualified technician in compliance with applicable regulations. Programmed operation logic: automatic function, semi-automatic,
pre-flashing, step-by-step by radio remote control, input for 2nd pair of photocells, electric lock output, pedestrian opening function, stroke reversing pulse function,
operator status indicator light. The Manufacturer declines responsibility for improper use of the programmer and reserves the right to amend and update this man
ual and the programmer without prior notice. Not-compliance with installation rules can cause serious damage to properties and people.
