fadini MEC 200 - Overall Dimensions

English
MEC 200
TECHNICAL SPECIFICATIONS
ELECTRIC MOTORS
Power output
Supply voltage
Frequency
Absorbed power
Absorbed current
Motor rotation speed
Capacitor
Intermittent service
Single-phase
0,37 kW (0,5 HP)
230 Vac
510 W
2,4 A
20 µF
Three-phase
0,37 kW (0,5 HP)
230/400 Vac
575 W
2,1/1,2 A
Single-phase
0,73 kW (1,0 HP)
230 Vac
50 Hz
1.130 W
5,7 A
1.380 rpm
30 µF
S3
Three-phase
0,73 kW (1,0 HP)
230/400 Vac
1.030 W
3,7/2,2 A
Three-phase
1,1 kW (1,5 HP)
230/400 Vac
1.500 W
5,1/3 A
OPERATOR
Rated torque
Gear rating
Travel speed
Working temperature
Oil type
Maximum gate weight
Horizontal Mec 200 weight
Vertical Mec 200 weight
Protection standard
Limit switch
PERFORMANCE
Frequency of use very intensive
Service cycle 25 s opening - 30 s dwell - 25 s closing - 30 s dwell
Complete cycle time 110 s
Complete opening - dwell - closing - dwell cycles No.33/hour
Annual cycles (with 8 hours of use per day) No. 96.000
Single-phase
40 Nm
1.200 kg
19,5 kg
19 kg
Three-phase
40 Nm
1.250 kg
18,5 kg
18 kg
Single-phase
80 Nm
1/32
10 m/1'
-25 °C +80 °C
Oil Fadini - Item 706L
1.800 kg
23,5 kg
23 kg
IP 55 (inside the cover)
mechanical
Three-phase
80 Nm
1.850 kg
21,5 kg
21 kg
Three-phase
110 Nm
2.000 kg
25,5 kg
25 kg
Mec 200 vertical
Mec 200 horizontal
OVERALL DIMENSIONS
FITTING ACCESSORIES FOR INSTALLING
Zinc-coated steel
base plate
260
200
120
Steel gear rack
22 x 22 mm thickness
2 m modules
Steel
gear rack xing set
Limit switch striking
plates for screw xing
to the gate
Power cut off
device
Steel gear rack
with xing slots
1 m modules
Nylon gear rack
8 mm thickness
steel core
1 m modules
290 mm
160 130
285
225
92
467
92
172
40
Z18 m4
Side viewFront view
E 17 release spanner
130
174
245
467
290
92
130 160
60
38
Side view
Top view
Z18 m4
electro-mechanical sliding gate operator
2003/108/CE Directive
Disposal of electric and
electronic equipment
DISPOSE PROPERLY OF MATERIALS
ARMFUL TO THE ENVIRONMENT
GB
2016/11
