14 8025/8030 CNC OPERATING MANUAL
3.1.2.2. STANDARD display mode.
This mode is automatically imposed on selecting the AUTOMATIC or SINGLE BLOCK
mode of operation.
Information displayed on screen.
. Upper part. The message AUTOMATIC or SINGLE BLOCK and then the number of the
program, of the first block to run or the one which is being run. Underneath, the contents
of the first block of the programme or of the block being run and the following (2 or 3).
. Central part. Under the titles COMMAND, ACTUAL and TO GO appear the axis arrival
dimensions, the current position and those still to travel, respectively.
. Lower part. The programmed values of F and S appear and their %, as well as the list of
activated G, T and M functions.
This part of the screen also displays messages sent to the CNC from the PLC, programmed
comments, as well as the meaning of the function keys.
