16 8025/8030 CNC OPERATING MANUAL
3.1.2.6. SUBROUTINE STATUS, CLOCK AND PARTS COUNTER display mode.
Identical to the STANDARD display mode, except that instead of the following blocks to be
run, the subroutines which are active at that moment appear with the following format:
Standard subroutines : N2.2
Subroutine number Number of times still to be run
Parametric subroutines : P2.2
Subroutine number Number of times still to be run
Repetition of subprograms (G25):
G25.2
Indicates that it is a Number of times still to be run
repetition of a
subprogram by means of
a G25, G26, G27,G28 or
G29 function.
Should there be any active canned cycle it is also displayed with the following format:
G2.2
Canned cycle code Number of times still to be run
The following also appears on the screen in this display mode:
The CLOCK which indicates in hours, minutes and seconds the operation time of the CNC
in the AUTOMATIC, SINGLE BLOCK, TEACH IN and DRY RUN modes.
When the running of a program is interrupted or finished, the counting of the clock is also
interrupted.
