8025/8030 CNC OPERATING MANUAL 27
Three-axis machine
XY plane (G17)
XZ plane (G18)
YZ plane (G19)
Four (five) -axis machine
a) If W (V) is incompatible with X
XY or WY (VY) plane (G17)
YZ or WZ (VZ) plane (G18)
YZ plane (G19)
b) If W (V) is incompatible with Y
XY or XW (VX) plane (G17)
XZ plane (G18)
YZ or WZ (VZ) plane (G19)
c) If W (V) is incompatible with Z
XY plane (G17)
XZ or XW (XV) plane (G18)
YZ or YW (YV) plane (G19)
- The movements are carried out to maximum programmable feedrate (F0), whatever the
programmed F’s may be.
- The % Feedrate may be varied with the Feedrate Override (M.F.O.) switch.
3 - RAPID TRAVERSE
The CNC will execute the program completely. The movements are executed at max.
programmable Feedrate (F0) regardless of the F’s programmed. The Feedrate Override allows
the % feed to be varied.
It should be borne in mind that if machine parameters P721, P722, P723, P728 are activated the
Acceleration/Deceleration control will also be applied in F0, avoiding the generation of
following errors.
4 - THEORETICAL PATH
The CNC will execute the program without moving the axes and without taking tool
compensation into account.
