26 8025/8030 CNC OPERATING MANUAL
3.4. MODE 4: DRY RUN
This operating mode is used for testing a program in a dry run before producing the first part.
3.4.1. Execution of a program
The execution of a program requires the following steps:
3.4.1.1. Selection of the operating mode DRY RUN (4)
- Press OP MODE
- Press key 4. The screen will display:
DRY RUN
0 - G FUNCTIONS
1 - G,S,T,M FUNCTIONS
2 - MAIN PLANE MOVE
3 - RAPID MOVE
4 - THEORETICAL PATH
0 - G FUNCTIONS
The CNC will only execute the programmed G functions.
1 - G,S,T,M FUNCTIONS
The CNC will only execute the programmed G,S,T,M functions.
2 - MOVEMENT ON THE MAIN PLANE
The CNC will execute the G,S,T,M functions plus the movements on the main plane.
