8025/8030 CNC OPERATING MANUAL 31
3.5. MODE 5: JOG
This operating mode is used for:
- Jogging the axes.
- Searching for the machine-reference points of the axes
- Presetting values on the axes
- Entering or executing F,S,M
- Operating as a readout
- Displaying/changing the RANDOM table
- RESETting the CNC (return to initial conditions).
- Handwheel operation.
- Measure and load the length of tools in the tool offset table, using a touch probe.
- Starting and stopping the spindle.
3.5.1. Selection of the JOG operating mode (5)
- Press OP MODE
- Press key 5
The coordinates of the axes will appear on the screen in large characters.
In 5 axis machines, to display the axis which is not active, the corresponding key, i.e., W or V,
must be pressed.
