8025/8030 CNC OPERATING MANUAL 33
3.5.4. Jogging the axes
3.5.4.1. Continuous movement
- Front panel (M.F.O.) switch in any position of the % FEEDRATE zone.
- According to the axis and the direction in which it is desired to move, the JOG key
corresponding to this axis must be pressed:
- As established by means of the machine-parameter:
. (P12=Y). Releasing the key, the movement is stopped.
. (P12=N). Two possibilities:
- Press to stop the movement.
or.
- Press another JOG key.
To reverse or transfer the movement of one axis to another.
Atention:
On selecting the JOG operating mode the feedrate F0 (defined by
parameter P830) remains selected. If this parameter is 0, then
P110,P210,P310,P410 and P510, corresponding to axes
X,Y,Z,(W),(V), respectively, will determine the max. feedrate for
each axis in the JOG mode.
Rapid feed of an axis in JOG mode can be obtained while pressing the
RAPID FEED key .
