34 8025/8030 CNC OPERATING MANUAL
3.5.4.2. Incremental movement
- Front panel M.F.O. switch in the JOG zone.
- Press any of the following keys:
The axis will move in the direction chosen, a distance equal to that indicated on the knob
position:
Atention:
a) On selecting the JOG operating mode the feedrate F0 (defined by
parameter P830) remains selected. If this parameter is 0, then
P110,P210,P310,P410 and P510, corresponding to axes
X,Y,Z,(W),(V), respectively, will determine the max. feedrate for
each axis in the JOG mode.
Rapid feed of an axis in JOG mode can be obtained while pressing the
RAPID FEED key .
b) The positions of the knob are 1,10,100,1000 and 10000, and indicate the
value of the movement in microns or in 0.0001 inches. This value can be
limited to 1000 microns or 10000 (of 0.1 or 1 inches) by P609(6).
3.5.5. Entering F,S and M
The required values of F,S and M may be entered in this operating mode.
3.5.5.1. Entering an F value
- Press the F key
- Key in the required value
- Press
