1 12024520 RETENCION DE VAPORES
2 12024500 GUIA RETENCION VAPORES
3 12023576 JUNTA BASE CHIMENEA
12010242 TORNIL. APLASTADO M5X13 A 304
4 12022868 CONJUNTO CHIMENEA
12010126 REMACHE EXAGONAL M.6
5 12024328 LEVA EJE CHIMENEA
12010258 VARILLA ROSCADA M4X16
6 12010014 ARANDELA DE SEGURIDAD Ø8
7 12023497 JUNTA EJE CHIMENEA
8 12024436 GUIA EJE CHIMENEA
S/Nº 12010274 JUNTA TORICA 9.19x2.62
12009944 ARANDELA A5
12009890 ARANDELA ABANICO A5 A.304
12010284 TUERCA EXAGONAL M5
9 12024435 EJE CHIMENEA ELECTRICA
12009876 TORNILLO ALOMADO M4X6 ZINC.
10 12009985 PLACA SEPARADORA
12010247 TORNILLO ALOMADO M3X20
12010289 TUERCA AUTOBLOCANTE M3
11 12025193 INTERRUPTOR PUERTA
12 12024638 MOTOR CHIMENEA
13 12022146 ESCUA. AMARRE MOTOR CHIMEN.
12009868 ARANDELA A6
12009882 ARANDELA ABANICO A6 A.304
12010186 TORNILLO EXAGONAL M6X15 A30
4
14 12024122 TUBO FLEXIBLE Ø53X360
12009962 ABRAZADERA 40*60
MOD.
HORNOS / OVEN ZONA / ZONE CHIMENEA / FLUEPIPE
PLANO
DIAGRAM
C-3004
ITEM
CODIGO
REFERENCE
DENOMINACION DENOMINATION
ACE-061
AE-061
APE-061
ACE-101
AE-101
APE-101
ELIMINADO
ELIMINATED
INTRODUCID.
INTRODUCED
NOTAS
CLOSE CHIMNEY 111111
STEAM RETAINER GUIDE 111111
FLUEPIPE BASE SEAL 111111
FLAT SCREW M.5x13 666666
COMPLETE CHIMNEY 111111
HEXAGONAL RIVET M.6 222222
FLUEPIPE SHAFT CAM 111111
THREADED ROD M4X16 111111
SAFETY WASHER Ø8 111111
FLUEPIPE SHAFT SEAL 111111
FLUEPIPE SHAFT GUIDE 111111
FLAT WASHER A.5 222222
FAN SHAPED WASHER A.5 222222
HEXAGONAL NUT M.5 222222
ELECTRIC FLUEPIPE SHAFT 111111
CURVED SCREW M4X6 ZINC. 111111
SPACER PLATE 444444
CURVED SCREW M3X20 444444
SELF-LOCKING NUT M3 444444
DOOR SWITCH 222222
FLUEPIPE MOTOR 111111
FLUEPIPE MOTOR FASTENING B
R
111111
WASHER A6 222222
FAN SHAPED WASHER A.6 222222
HEXAGONAL SCREW M6X15 222222
FLEXIBLE TUBE Ø53X360 111111
CLAMP 40*60 222222
O-RING 9.19x2.62 111111 01.03.13
- 13-
FAGOR INDUSTRIAL
