1 12024329 VARIADOR FRECUENCIA SIE 0,37
K
1 12048794 REP VARIADOR REGULADO 061E
1 12048798 REP VARIADOR REGULADO ADV
12009987 ARANDELA A4
12009928 ARANDELA ABANICO A4 A.304
12010278 TORNILLO ALOMADO M4X10
S/Nº 12025235 CONECTOR PASO 3,96MM 8 VIAS
2 12024642 CONJUN. TERMOPAR CAMARA (K)
3 12023581 RACORD CIERRE SONDA
S/Nº 12024247 BICONO CIERRE SONDA
4 12023737 BASE CIERRE SONDA
5 12023504 JUNTA PASAMUROS SIMPLE
12009987 ARANDELA A4
12010249 TORNILLO EXAGONAL M4X10
6 12039548 SONDA PINCHO ADVANCE
12010110 ARANDELA Ø 8.4X20X1.5
12040566 CONTRATUERCA H 1/4''
7 12024011 CONTACTOR 230 V. 50-60 HZ
8 12024591 TERMOSTATO LIMITADOR 10/21
9 12024884 TERMOSTATO LIMITADOR CORTE
S/Nº 12022001 SOPORTE TERMOS VAPOR
12023499 TUERCA M.10x1 EGO 00.00600.075
10 12025158 BORNAS PORTA FUSIBLES
11 12024040 CONTAC. SIRIUS 3R 230V.50-60
12 12043563 CHAPA CUADRO ELECT APE 061
12 12041913 CUADRO ELECTRICO 101-102 E
12010158 REMACHE EXAGONAL M.4
12009944 ARANDELA A5
12009890 ARANDELA ABANICO A5 A.304
12010221 TORNILLO EXAGONAL M5x1
5
1 26.02.13REGULATED VARIATOR ADV ___11
_ 26.02.13REGULATED VARIATOR 061E 111__
1 26.02.13FREQUENCY VARIATOR SIE 0.37 11111
MOD.
HORNOS / OVEN ZONA / ZONE CUADRO ELECTRICO / ELECTRIC PANEL
PLANO
DIAGRAM
C-3007
ITEM
CODIGO
REFERENCE
DENOMINACION DENOMINATION
ACE-061
AE-061
APE-061
INTRODUCID.
INTRODUCED
NOTAS
ACE-101
AE-101
APE-101
ELIMINADO
ELIMINATED
FLAT WASHER A.4 666666
FAN SHAPED WASHER A.4 666666
CURVED SCREW M.4x10 666666
CONNECTOR ROUTES 3,96MM 8 111111
CHAMBER THERMOCOUPLE UNI
T
111111
PROBE CLOSING ADAPTOR 222222
PROBE CLOSING BICONE 111111
FIXING CORE PROBE 111111
SIMPLE 111111
FLAT WASHER A.4 444444
HEXAGONAL BOLT M4X10 444444
ADVANCE PROBE PINCHO 111111
FLAT WASHER Ø 8.4X20X1.5 111111
COUNTERNUT H 1/4'' 111111
230 V. 50-60 HZ CONTACTOR 111111
LIMITER THERMOSTAT10/21 111111
THERMOSTAT LIMITER _11_11
THERMOSTAT SUPPORT 222222
NUT M.10x1 EGO 00.00600.075 222222
FUSE HOLDER TERMINAL 222222
SIRIUS 3R 230V.50-60 CONTAC. 233466
ELECTRICAL PANEL APE 061 111___
ELECTRICAL PANEL 101-102 E ___111
HEXAGONAL RIVET M.4 666666
FLAT WASHER A.5 333333
FAN SHAPED WASHER A.5 333333
HEXAGONAL SCREW M.5x15 333333
- 20-
