LEVELLING AND POSITIONING
LEGS - LEVELLING
WORKTOP
If the worktop is
wooden, fit the plastic
protection onto it to
prevent the area from
being damaged by
steam.
Fit the front brackets to
the dishwasher so that
it can be fixed to
neighbouring units or
the work surface (see
point k, page 54).
a
b
c
d
e
a
b
e
To flush-mount the
dishwasher in a row of
kitchen fittings sharing
the same plinth, loosen
and remove the base
accessories.
Before fitting the
dishwasher into the
space, raise it up to
the height of the
worktop by turning the
rear legs until a space
of some 3 mm is left
from the top.
Then adjust the front
legs to the desired
height. Some
integrated models
include a rod for
levelling the rear legs
from the front.
e
d
c
d
To install an integrated
dishwasher:
