2.7. Installation in 28 to 36 kg TP2 industrial dryers
Remove the upper dryer panel.
Remove the door panel. The door is pressure-mounted. Just separate the door with the hinge by pulling
on it. To mount it, proceed in the same way but insert it in the notches of the pin.
Hinge 12165655
