37
The terminal strip is connected to the right of the fan contactor, together with the other strips already
mounted.
Next connect the neutral and phase from the pump on the corresponding connectors.
Install one end on the DIN rail.
Install the other end on the plate. If you already have the connector, install the cable in the empty slot.
