The dosing cycle can be configured using 5 different parameters. Each parameter is described below.
→Target dosing temperature (ºC/ºF). As soon as the temperature falls below this objective
temperature, the dosage operation will take place. Min. 25 ºC, max. 60 ºC.
→Dosing shake-up time (minutes). This is the time during which the drum rotates after dosage, to
ensure the product is distributed uniformly. Min. 1 minute, max. 15 min.
→Dosage time (seconds). This is the length of time the dosage application lasts in seconds. Min.
1 second, max. 99 s.
→Rotation reversal (seconds): in the same way that ON/OFF is selected during a drying cycle. If
OFF is selected, it rotates in a clockwise direction continuously. If ON is selected, the clockwise rotation
time and the anti-clockwise rotation time are selected. Min. 20 seconds, max. 300 s.
→Drum rotation speed: as in the drying cycle, four different speed types can be selected:
• Minimum (1)
• Low (2)
• Normal (3)
• High (4)
