FPS
™
Design Guide
FPS
™
Core Products
Product/Function
Function
Par
t Typical Output Power Output Power Peak Current Drain Voltage Static Drain Source Switching Packages
Number Applications (85 – 265Vac) (230Vac) ±15% Limit MAX On Resistance MAX Frequency
(W) (W) (A) (V) (Ω) (kHz)
FSD200 Charger 4.8 7.2 0.3 700 32 134 DIP-7L
FSD210 Charger 4.8 7.2 0.3 700 32 134 DIP-7L
FSDM311
PC Aux 7.2 7.2 0.6 650 19 67 DIP-8L
FSD1000 PC 12.0 13.6 Adjustable 700 9 70 DIPH-12L
FSDL0165RN DVDP/STB 12.0 13.6 1.2 650 10 50 DIP-8L
FSDL312 PC Aux 12.0 13.6 1.2 650 10 50 DIP-8L
FSDM0265RN DVDP/STB 16.0 18.4 1.5 650 6 67 DIP-8L
FSDH0265RN DVDP/STB 16.0 18.4 1.5 650 6 100 DIP-8L
FSDL0365RN DVDP/STB 24.0 28.0 2.2 650 4.5 50 DIP-8L
FSDM0365RN DVDP/STB 24.0 28.0 2.2 650 4.5 67 DIP-8L
FSDM0565R LCD Monitor 48.0 56.0 2.3 650 2.2 67 TO-220F-6L
FSDM07652R LCD Monitor 60.0 68.0 2.5 650 1.6 67 TO-220F-6L
FS7M0680 PDP, PC 64.0 80.0 4.0 800 2.0 67 TO-3P-5L
FS7M0880 PDP, PC 88.0 104.0 5.0 800 1.5 67 TO-3P-5L
FS8S0765RCB CRT Monitor 64.0 80.0 4.0 650 1.6 sync TO-220-5L
FS8S0965RCB CRT Monitor 96.0 116.0 6.0 650 1.2 sync TO-220-5L
FS6S1265RE CRT Monitor 128.0 152.0 8.0 650 0.9 sync TO-3P-5L
FS6S1565RB CRT Monitor 160.0 192.0 9.7 650 0.65 sync TO-3P-5L
KA5Q0765RTH C-TV 80.0 104.0 5.0 650 1.6 QRC TO-220F-5L
KA5Q1265RF C-TV 160.0 184.0 8.0 650 0.9 QRC TO-3PF-5L
KA5Q1565RF C-TV 216.0 240.0 11.5 650 0.65 QRC TO-3PF-5L
Control Feature/Protection Mode
Control Feature Protection Mode
Part Soft Frequency Green FPS
™
Bias Feedback Over Load Thermal Over Current Over Voltage Under Volt.
Number Start Modulation Family Winding Mode Protection Shutdown Protection Protection Lock Out
FSD200 Internal Soft Start Yes Yes Not Needed Voltage Auto Restart Auto Restart No No No
FSD210 Internal Soft Start Yes Yes Needed Voltage Auto Restart Auto Restart No No Yes
FSDM311 Internal Soft Start No Yes Needed Voltage Auto Restart Auto Restart No Auto Restart Yes
FSD1000 Internal Soft Start No Yes Needed Current/Voltage Auto Restart Auto Restart No Latch Yes
FSDL0165RN Internal Soft Start Yes Yes Needed Current Auto Restart Auto Restart Auto Restart Auto Restart Yes
FSDL312 Internal Soft Start Yes Yes Needed Current Auto Restart Auto Restart Auto Restart Auto Restart Yes
FSDM0265RN Internal Soft Start Yes Yes Needed Current Auto Restart Auto Restart Auto Restart Auto Restart Yes
FSDH0265RN Internal Soft Start Yes Yes Needed Current Auto Restart Auto Restart Auto Restart Auto Restart Yes
FSDL0365RN
Inter
nal Soft Star
t
Y
es Yes Needed Current Auto Restart Auto Restart Auto Restart Auto Restart Yes
FSDM0365RN Internal Soft Start Yes Yes Needed Current Auto Restart Auto Restart Auto Restart Auto Restart Yes
FSDM0565R Internal Soft Start No Yes Needed Current Auto Restart Auto Restart Auto Restart Auto Restart Yes
FSDM07652R
Inter
nal Soft Start No Yes Needed Current Auto Restart Auto Restart Auto Restart Auto Restart Yes
FS7M0680 Soft Start No No Needed Current Latch Latch Latch Latch Yes
FS7M0880 Soft Start No No Needed Current Latch Latch Latch Latch Yes
FS8S0765RCB Soft Start No No Needed Current Auto Restart Auto Restart Auto Restart Auto Restart Yes
FS8S0965RCB Soft Start No No Needed Current Auto Restart Auto Restart Auto Restart Auto Restart Yes
FS6S1265RE
Soft Star
t
No
No
Needed Current Auto Restart Auto Restart Auto Restart Auto Restart Yes
FS6S1565RB
Soft Start No No Needed Current Auto Restart Auto Restart Auto Restart Auto Restart Yes
KA5Q0765RTH No No No Needed Current Auto Restart Latch Latch Auto Restart Yes
KA5Q1265RF
No
No
No Needed Current Auto Restart Latch Latch Auto Restart Yes
KA5Q1565RF No No No Needed Current Auto Restart Latch Latch Auto Restart Yes
