FPS
™
Design Guide
Complete FPS
™
Product Offering Sorted By Output Power
Function
Par
t Recommended Typical Output Power Output Power Peak Current Drain Static Drain Source Switching Packages
Number
Replacement Applications (85-265Vac) (230Vac) ±15% Limit Voltage MAX on Resistance Frequency
(W)
(W) (A) (V) MAX (
Ω)
0 to 10W Output Power Range
FSD200 Charger 4.8 7.2 0.3 700 32 134kHz DIP-7L
FSD210 Charger 4.8 7.2 0.3 700 32 134kHz DIP-7L
FSDH0165D FSDM311 Charger 7.2 7.2 0.5 650 18 100kHz DIPH-8L
FSDM311 PC Aux 7.2 7.2 0.6 650 19 67kHz DIP-8L
KA5H0165RN FSDL0165RN Charger Aux 8.0 8.0 0.6 650 10 100kHz DIP-8L
KA5L0165RN FSDL0165RN Charger Aux 8.0 8.0 0.6 650 10 50kHz DIP-8L
KA5M0165RN FSDL0165RN Charger Aux 8.0 8.0 0.6 650 10 67kHz DIP-8L
10 to 50W Output Power Range
FSD1000 PC 12.0 13.6 Adjustable 700 9 70kHz DIPH-12L
FSDL0165RN DVDP/STB/VCR 12.0 13.6 1.2 650 10 50kHz DIP-8
FSDL312 PC Aux Power Supply 12.0 13.6 1.2 650 10 50kHz DIP-8L
KA5H0165R FSDH0265RN Charger Aux 12.0 12.0 0.6 650 10 100kHz TO-220F-4L
KA5H02659RN FSDH0265RN Aux Power Supply 12.0 13.6 0.9 650 6 100kHz DIP-8L
KA5L0165R FSDM0265RN Charger Aux 12.0 12.0 0.6 650 10 50kHz TO-220F-4L
KA5M0165R FSDM0265RN Charger Aux 12.0 12.0 0.6 650 10 67kHz TO-220F-4L
KA5M02659RN FSDM0265RN Aux Power Supply 12.0 13.6 0.9 650 6 67kHz DIP-8L
FSDH0265RN DVDP/STB/VCR 16.0 18.4 1.5 650 6 100kHz DIP-8L
FSDM0265RN DVDP/STB/VCR 16.0 18.4 1.5 650 6 67kHz DIP-8L
KA5H0265RC FSDM0365RN Aux Power Supply 20.0 24.0 1.2 650 6 100kHz TO-220-5L
KA5H0280R DVDP/STB/VCR 20.0 24.0 1.2 800 7 100kHz TO-220F-4L
KA5L0265R FSDL0365RN Aux Power 20.0 24.0 1.2 650 6 50kHz TO-220F-4L
KA5L0365RN FSDL0365RN DVDP/STB/VCR 20.0 24.0 2.2 650 4.5 50kHz DIP-8L
KA5M0265R FSDM0365RN Aux Power Supply 20.0 24.0 1.2 650 6 67kHz TO-220F-4L
KA5M0280R DVDP/STB/VCR 20.0 24.0 1.2 800 7 67kHz TO-220F-4L
KA5M0365RN FSDM0365RN DVDP/STB/VCR 20.0 24.0 2.2 650 4.5 67kHz DIP-8L
FSDL0365RN DVDP/STB/VCR 24.0 28.0 2.2 650 4.5 50kHz DIP-8L
FSDM0365RN DVDP/STB/VCR 24.0 28.0 2.2 650 4.5 67kHz DIP-8L
KA5H0365R DVDP/STB/VCR 32.0 40.0 2.2 650 4.5 100kHz TO-220F-4L
KA5H0380R DVDP/STB/VCR 32.0 40.0 2.2 800 5 100kHz TO-220F-4L
KA5L0365R DVDP/STB/VCR 32.0 40.0 2.2 650 4.5 50kHz TO-220F-4L
KA5L0380R DVDP/STB/VCR 32.0 40.0 2.2 800 5 50kHz TO-220F-4L
KA5M0365R DVDP/STB/VCR 32.0 40.0 2.2 650 4.5 67kHz TO-220F-4L
KA5M0380R DVDP/STB/VCR 32.0 40.0 2.2 800 5 67kHz TO-220F-4L
FSDM0565R LCD Monitor 48.0 56.0 2.3 650 2.2 67kHz TO-220F-6L
50 to 100W Output Power Range
FSDM07652R LCD Monitor 60.0 68.0 2.5 650 1.6 67kHz TO-220F-6L
FS6M12653RTC LCD Monitor 64.0 76.0 3.2 650 0.9 70kHz TO-220F-5L
KA5M0765RQC FSDM07652R LCD Monitor 80.0 96.0 5.0 650 1.6 67kHz TO-220-5L
FS7M0680 Plasma Display, PC 64.0 80.0 4.0 800 2.0 67kHz TO-3P-5L
KA5P0680C PC 64.0 80.0 4.0 800 2 Adjustable TO-220-5L
FS7M0880 Plasma Display, PC 88.0 104.0 5.0 800 1.5 67kHz TO-3P-5L
KA5M0965Q LCD Monitor 96.0 116.0 6.0 650 1.2 67kHz TO-3P-5L
60-160W Output Power Range
FS6S0765RCH FS8S0765RCB CRT Monitor 64.0 80.0 4.0 650 1.6 sync TO-220-5L
FS6S0965R FS8S0965RCB CRT Monitor 96.0 116.0 6.0 650 1.2 sync TO-3P-5L
FS6S0965RCB FS8S0965RCB CRT Monitor 96.0 116.0 6.0 650 1.2 sync TO-220-5L
FS8S0765RCB CRT Monitor 64.0 80.0 4.0 650 1.6 sync TO-220-5L
FS8S0965RCB CRT Monitor 96.0 116.0 6.0 650 1.2 sync TO-220-5L
FS6S1265RE CRT Monitor 128.0 152.0 8.0 650 0.9 sync TO-3P-5L
FS6S1565RB CRT Monitor 160.0 192.0 9.7 650 0.65 sync TO-3P-5L
50-220W Output Power Range
KA5Q0565RT C-TV 56.0 64.0 3.5 650 2.2 QRC TO-220F-5L
KA5Q0740RT C-TV 80.0 5.0 400 1.1 QRC TO-220F-5L
KA5Q0765RTH C-TV 80.0 104.0 5.0 650 1.6 QRC TO-220F-5L
KA5Q12656RT C-TV 120.0 144.0 6.0 650 0.9 QRC TO-220F-5L
KA5Q1265RF C-TV 160.0 184.0 8.0 650 0.9 QRC TO-3PF-5L
KA5Q1565RF C-TV 216.0 240.0 11.5 650 0.65 QRC TO-3PF-5L
FSCQ0765RT* C-TV 80.0 104.0 5.0 650 1.6 QRC TO-220F-5L
FSCQ15658RT* C-TV 160.0 184.0 8.0 650 0.65 QRC TO-220F-5L
48V DC/DC Flyback Converter
FS6X1220RT DC/DC Off-line 3.2 200 0.3 300kHz TO-220F-5L
FS6X1220RD* DC/DC Off-line 3.2 200 0.3 300kHz D2-PAK-5L
* In development
