FPS
™
Design Guide
Simplified Application Cir
cuit for FPS
™
Featur
es
• Optimal Solution for Off-Line SMPS
• Integrated Avalanche Rugged SenseFET
• Pulse-by-Pulse Current Limiting
• Various Protection Functions
(Over Voltage, Over Load, Over
Current, Thermal Shutdown)
• Burst Mode Operation for Low
Standby Power
• Frequency Modulation for Reduced EMI
• Soft Start Function
• Operation Fr
equency Options
(50/70/100/134kHz)
• External Frequency Synchronization
• Quasi Resonant
Snubber
Circuit
Load
+
+
++
Feedback
Circuit
Control
IC
FPS™
Advantages
• Low Standby Consumption with Burst Mode Operation
• Fully Avalanche Rugged, 650V and 800V SenseFETs Improves Reliability
•
Reduced EMI with Fully Integrated Frequency Modulation
• Reduces the Total Bill-of-Materials Cost with Integrated Protection and Control Functions
• Br
oad Application Coverage with Extensive Exper
tise and Easy-to-Use Design T
ools
Green FPS™ Features and Advantages
FPS™ Parallel Dice Solution
(Side-by-Side)
GNDVccIpk FB
Drain
Drain
Vstr Drain
SenseFET
PWM
IC
FPS™ Single Die Solution
(BCDMOS)
GND
GNDVFB GND
Vstr
Drain
Vcc
