Fairport PP46 - Water Sprinkler Kit

12. PARTS LIST – WATER SPRINKLER KIT
Part No Description Qty
W14595 Strap (Honda) 1
W14608 Strap (Briggs & Stratton) 1
W14594 Tank bracket (Honda) 1
W14607 Tank bracket (Briggs & St) 1
W80528 Clip 4
W80568 Tank 1
W80588 Tap 1
W51675 Hose tail 1
W80589 3/8” BSP nipple nut 1
W523/8 ½” fibre washer 1
W80045 Feed pipe, ¼” x 3/8” State length required
W14596 Sprinkler bar 1
W14598 Clamp plate 2
W87859 ¼” BSPT Socket Plug 2
W435/6/55 M6 x 55 Hex Bolt 4
W480/6 M6 Nyloc nut 4
W435/8/35 M8 x 35 Hex Bolt 4
W480/8 M8 Nyloc nut 4
W439/8 M8 star washer 8
93052 Complete kit for Honda, includes all above parts.
