Falco VL35F230 - User Manual

Questions and Answers

D
David BrandtAug 5, 2025
Why does the Falco VL35F230 hydraulic system make abnormal sounds?
- A
  anthonyknightAug 5, 2025
  Abnormal sounds in the hydraulic system may be due to several reasons. The oil filter might be clogged, in which case you should clean it. Another cause could be air in the system; try lifting the collar to its maximum height, holding it for 2-3 seconds, and then lowering it, repeating this process 2-3 times. Also, the surfaces between the sliding blocks and columns may not be lubricated, so add lubrication.
C
Chris JenkinsAug 11, 2025
What to do if the Falco Lifting Systems generator does not work?
- N
  Natasha CarneyAug 12, 2025
  If the generator isn't working, it might be due to a malfunctioning power source or power equipment. You should check the power source and other electrical components, including the fuses.
M
maureenellisonAug 17, 2025
Why does the collar automatically lower in working mode on my Falco Lifting Systems?
- J
  Jonathan WadeAug 18, 2025
  If the collar lowers automatically while in working mode, it could be due to several issues. The pistons may have lost their effectiveness, requiring you to fix them. Alternatively, the pipes might be leaking oil, in which case you should change the seals and tighten the nuts on the connection. It's also possible that the seals on the hydraulic cylinders have lost effectiveness, necessitating a change of the seals.
V
Victoria FarleyAug 22, 2025
What to do if the main and supplementary lift support mechanisms don’t move together on Falco VL35F230?
- A
  Andrea WebsterAug 23, 2025
  If the lift support mechanisms don't move together, it's likely that the equilibrium cables have stretched out after use, losing their tension. To resolve this, adjust the nut on the steel cables to add tension.
K
Kara WallaceAug 28, 2025
Why does the collar creep when raising and lowering on Falco Lifting Systems?
- J
  Jacob AguilarAug 29, 2025
  Collar creep during raising and lowering could be because the space between the sliding blocks and the columns is too narrow. You should select sliding blocks that will leave a gap of 1.5 to 2.5mm between the blocks and the column.
