II. SPECIFICATIONS AND STRUCTURE
SPECIFICATIONS
Drive Wheel 7.3” (186mm) solid wheel
Front Wheel 7.16” (182mm) solid wheel
Anti-tip Wheel 2.2” (56mm) solid wheel
Limit Speed Forward speed, 6 km/h, rev. speed 3.5 km/h
Braking System Intelligent brake
Distance between Ground and Footplate 3.5” (90mm)
Turning Radius 31.5” (800 mm)
Dimensions 37.4” x 16.6” x 32.4” (950 x 500 x 825 mm)
Seat Unit Standard light backrest w/folding sponge seat
Drive System Single motor drive
Batteries 12v/12Ah x 2 pcs
Motor Power 24v 180w
Travel Ranging 10.5 miles (17 kilometers)
Charger 24v 2A portable
Weight capacity Rated of 165 lbs (75kg.) maximum
Climbing Slope Rated of 8 maximum of 12
Charging Time 10-12 hours
Main frame: 53 lbs. (24kg)
Seat Unit: 22 lbs. (10kg)
Component Weight Batteries: 19.8 lbs. (9 kg) per unit
