7
For convenience of transportation and reduction of possible damage, the batteries and the seat unit are separately
packaged, so you need to assemble them onto the main frame of your scooter.
OPENING THE PACKING BOX
Open the packing box of your new scooter, and take off all protective liner, then take the scooter
from the box.
ADJUSTING ANGLE OF TILLER
• Loosen the lock-nuts(see fig. 4)
• Lift the tiller up to a proper angle for yourself
• Tighten the lock-nuts to fix the tiller
ASSEMBLING THE SEAT SUPPORT
• Insert the seat support into the seat tube located on the rear section(see fig. 5)
• Align the bolt hole
• Insert the bolt into the hole
III. INITIAL ASSEMBLY
