8
ASSEMBLING BATTERY UNIT
Put battery into trough, align electrode terminal on battery with that in the trough
(see fig. 6)
Turn safety lock on the back of the scooter that holds the battery in position.
ASSEMBLING SEAT UNIT
• Put the seat onto the seat support(see fig. 7)
• Pull out the seat-lock lever, adjust seat to the position, as you like. The seat will be locked
automatically.
• Insert left and right armrests into square tube separately
• Adjust to the position, as you like and lock-nuts.
ASSEMBLE BASKET
• Take off the 2 screws located on the front
of tiller(see fig. 8)
• Place basket on the front of tiller.
• Insert the net-basket into the receiver
Note: The basket can be ordered separately.
III. INITIAL ASSEMBLY
!
CAUTION!
Please always keep the electrode clean before installment, if not, it will influence the
effect of contact between battery packs and electrode terminal.
Wrong connection of battery will cause the scooter to be out of operation.
