9
For convenience to transport and store, your scooter has been designed to be disassembled and be assembled
easily without any special tools. You can easily disassemble the scooter into four pieces, the front section, the rear
section, the seat unit and the batteries (see fig. 9). You can assemble these pieces together quickly when you
follow these instructions.
DISASSEMBLY
• Shut off the power and pull the lock lever under the seat base to unlock the seat
• Lift the seat up and off the scooter(see fig. 7)
• Turn release lever on back of scooter to release the battery
• Lift the battery case up(see fig. 6)
• Loosen the plug from the front and rear power connector, then remove it(see fig. 10)
• Pull the ring on the lock hook and move it forward to release the two sections(see fig. 11)
• Lift the front and rear section from the middle(see fig. 12)
• Loosen the knob on the end of tiller, the incline the tiller(see fig. 4)
IV. DISASSEMBLY
