Appendix A
Table 1: Specifications for Confined Space Davit System
Part Numbers
Minimum Tensile Strength
and Material
Maximum User Capacity
Standards &
Regulaons
12” to 29” Oset Arm
6500128
6061-T6 Aluminum
Zinc Plated Steel
Minimum 5,750 -lb
Moment Rated
Minimum 5,000 lbs Rated
in Rescue Point
Conguraon
Minimum 1,800 lbs Rated
in Normal Operaon
See Figure 10 for Complete
Minimum Load Rangs
Maximum Two Workers at
up to 310 lbs. Each (620
lbs. Total) for
Rescue Conguraons
Maximum One Worker up
to 310 lbs. for Normal
Conned Space Entry/
Egress Operaons
OSHA 1926.502
3pc Portable Base for
12” to 29”
Oset Davit Arm
6500728
24” to 44” Oset Arm
6500244
6061-T6 Aluminum
Zinc Plated Steel
Minimum 81,000 in-lb
(9,151 Nm)
Moment Rated
Minimum 5,000 lbs Rated
in Rescue Point
Conguraon
Minimum 1,800 lbs Rated
in Normal Operaon
See Figure 14 for Complete
Minimum Load Rangs
3pc Portable Base for
24” to 44”
Oset Davit Arm
6500844
Lower
Mast/Extensions
6500321
6500433
6500545
6500657
6061-T6 Aluminum
Zinc Plated Steel
