Drum stand assembly
1
1 Set up the drum stand.
2 Put the long cymbal tube/short cymbal tube/L shape pad rod into the drum stand.
3 Put the pads/cymbal/module to the relative position.
long cymbal tube
long cymbal tube
L shape pad rod
L shape pad rod
L shape pad rod
L shape pad rod
short cymbal tube
CRASH RIDE
HI-HAT
TOM1 TOM2
KICK
TOM3
SNARE
HI-HAT CONTROL
MODULE
