- 6 -
1. Disconnect the power supply.
2. Mount the meter on a rail in the distribution box.
3. Connect the input phase to terminal 1.
4. Connect the N wire to terminal 4.
5. Connect the measured circuit or a single receiver to terminal 3
(output phase L) and terminal 6 (N).
6. Connect an additional pulse receiver to terminals 20 (+)i 21(–).
An additional pulse receiver is not required.
reference voltage 230 V AC, 50 Hz
base current 5 A
maximum current 45 A
minimum detection current 0.02 A
accuracy class (EN50470-1/3) B
energy consumption of the meter <8 VA; <0.4 W
rang of indications 0÷99999.99 kWh
meter constant (1 Wh/imp) 1000 imp/kWh
readout indication LED red
SO+ SO- pulse output open collector
SO+ SO- connection voltage <27 V DC
SO+ SO- connection current <27 mA
SO+ SO- constant (1Wh/imp) 1000 imp/kWh
length of the SO+ SO- cable <20 m
SO+ SO- pulse time 90 ms
working temperature -25÷55°C
Mounting
Technical data
