2. PRODUCT DESCRIPTION & SPECIFICATIONS
PRODUCT DESCRIPTION
Industrial diesel or kerosene portable radiant heater with open combustion chamber.
SPECIFICATIONS
MODEL HDR40
Heat Output*
40KW
136,480 BTU
Air Flow (L/s) 165
Fuel Type Diesel or Kerosene
Fuel Consumption
(L/h)
3.8
Fuel Nozzle Size (gph)
Voltage (V/Hz) AC220-240V/50
Current Rating (A) 0.33
Electrical Power (W) 80
Net Weight (kg) 27.2
Dimensions (mm) 925(L)*635(W)*860(H)
Tank Capacity (L) 38
Operating Range (H) ~10
OPERATING PRINCIPLE
Air ow is necessary to ensure proper combustion, it is supplied by the internal burner
fan. The air enters the burner funnel and gets mixed with a high-pressure fuel. The fuel
ow is secured by an electrical pump, which sucks the fuel away from the tank and
moves it to the nozzle under high pressure.
