Cold Water Rheology Instruction Manual
372144 Revision D, May 2012 7
3 Features and Specifications
The Cold Water Rheology Kit is compact and portable. Its components are
contained in a durable carrying case.
This kit includes a digital circulating bath and a double-walled sample cup. To
maintain the temperature, insulating material is also included to cover the cup and
the tubing through which the cooling mixture flows. The digital circulating bath
features controlled cooling and programmable settings.
Table 3-1 Specifications
Category Specification
Bath capacity 6 liters
Temperature range
- 20 to 100
o
C
- 4 to 212
o
F
Bath Dimensions
(Width x Height x Length)
8 x 24.2 x 16.3 inches
20.3 x 61.5 x 41.4 centimeters
Flow rate, maximum 15 L/min
Cooling Capacity 250 W
Heater Wattage
1000 W (P/N 207952)
1200 W (P/N 207953)
Power
115 V, 50/60 Hz, 15 Amps (P/N 207952)
230 V, 50/60 Hz, 10 Amps (P/N 207953)
