ESC USERS MANUAL
• All R&D done in the USA.
• Specifically designed for the highest level of stock and mod competition, with advanced firmware, for the ultimate power,
response, and control.
• 32-bit high-performance CPU.
• 2,303 Strand, 11awg, Ultra Low Resistance Wire.
• CNC Machined Red/Black Aluminum Case w/ Integrated Heat Sink.
• High-Turbulence Heat Sink Design - Optimizes airflow for maximum cooling.
• Ultra-Low Resistance FET Board.
• 3 Integrated Max Power Capacitors.
• 25mm Fan w/ Aluminum Fan Cover.
• Heavy-Duty Solder Posts.
• On-Board Power Button with LED.
• Blinky Mode Software.
• Off-By-Radio Function.
• Ultra-smooth, Precision Throttle & Brake Frequency Adjustment.
• Ultra-Precision Throttle, Brake, and Punch Control.
• Fully programmable with the Fantom LCD Program Card by itself (sold separately), or you can Program the ESC or Update
the ESC Firmware with the Fantom LCD Program Card combined with the advanced PC Interface (see instruction in the LCD
Program Card User Manual).
• Multiple protection features include low voltage cut-off protection, over-heat protection, and throttle signal loss protection.
• Compatible with Sensored and Sensorless Brushless Motors.
• Data Analysis Capability includes RPM, Low Voltage and ESC Temperature.
FEATURES:
SPECIFICATIONS:
Continuous Current
BEC Output
Size (L x W x H) mm without fan
Weight (not including wiring and fan)
LCD Program Card
Recommended Applications
Sensored
Sensorless
Motor Limit (2S LiPo - motor timing at 0˚)
Battery Input
3.7V per cell LiPo
1.2V per cell NiMH
160A
2-3 Cells
4-6 Cells
Linear 6V / 7.4V Adjustable / 5A
38 x 30.6 x 19.3
48g
✓
2S-3S 1/10th Scale
✓
Compatible but not optimal
4.5 Turn or over
95A
2 Cells
4-6 Cells
Linear 6V / 7.4V Adjustable / 3A
31.5 x 25.6 x 15.1
45g
✓
2S 1/10th Scale
✓
Compatible but not optimal
6.5 Turn or over
MODELS FR-10 PRO 160A FR-10 PRO STOCK 95A
