Fantom FR-10 ESC - Led Indication

WWW.FANTOMRACING.COM
ESC USERS MANUAL
• RED LED blinking during operation: When the ESC is in “Modified” mode, this indicates that the battery has reached
the default Low Voltage cut-off, or the Low Voltage cut-off setting that you customized with the LCD Program Card
(see LCD Program Card manual). Once this function is activated, power to the motor will stop. When the ESC is in “Stock”
mode, this LED function is disabled, but power will still stop to the motor, if the battery reaches the low voltage cut-off that
you have set.
• BLUE+RED LED blinking during operation: When the ESC is in “Modified” mode, this indicates that the ESC has
reached the default Over-heat temperature, or the Over-heat temperature setting that you customized with the LCD
Program Card (see LCD Program Card manual). Once this function is activated, the ESC will reduce power to the motor by
50%. When the ESC is in “Stock” mode, this LED function is disabled, but power will still be reduced to the motor, if the ESC
reaches the over-heat temperature that you have set.
• BLUE LED blinking in neutral position: This indicates that the ESC is in Stock Mode (Blinky / Zero Timing). Turbo and
boost cannot be accessed in this mode.
• BLUE LED on solid in neutral position: This indicates that the ESC is in Modified Mode. Turbo and boost can be
accessed and adjusted in this mode.
Battery Low Voltage Warning
ESC Over-Heat Warning
Stock (Blinky) Mode
Modified Mode
Red LED
Red + Blue (purple) LED
Blue LED
Blue LED
Blinking (in modified mode only)
Blinking (in modified mode only)
Blinking (throttle in neutral position)
On Solid (throttle in neutral position)
FUNCTION LED LED STATUS
LED INDICATION
